Semi-Float Axles for the Jeep Wrangler JK, JL and the Gladiator JT from Dana

PROBLEM
"I want to upgrade to an Ultimate Dana 60® axle, but it has an 8-bolt wheel-end pattern while my stock semi-floating axle has a 5-bolt pattern; I’d have to invest in a brand-new 8-bolt wheel and brake package!"

SOLUTION
The Ultimate Dana 60® Semi-Float Axle delivers all the benefits—like Spicer® ring and pinion gearing, heavy-duty brackets, and more—and all the convenience of adhering to a semi-floating axle design: get a direct-fit, bolt-in solution and reuse your wheels and brakes.

UD60 LogoFor a direct-fit solution that’s built for superior strength, Dana now offers the Ultimate Dana 60® Semi-Float Axle for the Jeep Wrangler JK, JL and the Gladiator JT. You can get all the benefits of the celebrated Ultimate Dana 60® axle—like Spicer® chromoly steel axle shafts, Spicer ring and pinion gearing, a nodular iron diff cover, heavy-duty brackets, and more—while enjoying optimum weight capability.

If you’re upgrading from a stock semi-float, you can reuse all of your wheels and brakes! These semi-float axles are also a perfect choice to match up with an Ultimate Dana 44™ front axle, which allows you to reuse factory 5-lug hubs. Get added strength and peace of mind when navigating extreme terrain with the Ultimate Dana 60® Semi-Float Axle.

UD60 Semi Float

The Iconic Ultimate Dana 60® Axle, Reimagined with a 5- or 6-Bolt Pattern

Check out our streamlined ecommerce and parts locator platform DanaAftermarket.com, see our Where to Buy page, or visit one of our Distribution Partners below.

Part Number Vehicle Ratio Locker
SF-L60JK373E-69 Jeep Wrangler JK 3.73 E-Locker
SF-L60JK410E-69 Jeep Wrangler JK 4.10 E-Locker
SF-L60JK456E-69 Jeep Wrangler JK 4.56 E-Locker
SF-L60JK488E-69 Jeep Wrangler JK 4.88 E-Locker
SF-L60JK538E-69 Jeep Wrangler JK 5.38 E-Locker
SF-L60JL373E-69 Jeep Wrangler JL 3.73 E-Locker
SF-L60JL410E-69 Jeep Wrangler JL 4.10 E-Locker
SF-L60JL456E-69 Jeep Wrangler JL 4.56 E-Locker
SF-L60JL488E-69 Jeep Wrangler JL 4.88 E-Locker
SF-L60JL538E-69 Jeep Wrangler JL 5.38 E-Locker
SF-L60JT373E-69 Jeep Gladiator JT 3.73 E-Locker
SF-L60JT410E-69 Jeep Gladiator JT 4.10 E-Locker
SF-L60JT456E-69 Jeep Gladiator JT 4.56 E-Locker
SF-L60JT488E-69 Jeep Gladiator JT 4.88 E-Locker
SF-L60JT538E-69 Jeep Gladiator JT 5.38 E-Locker
SF-L60JK456A-69 Jeep Wrangler JK 4.56 ARB Air Locker
SF-L60JK488A-69 Jeep Wrangler JK 4.88 ARB Air Locker
SF-L60JK538A-69 Jeep Wrangler JK 5.38 ARB Air Locker
SF-L60JL456A-69 Jeep Wrangler JL 4.56 ARB Air Locker
SF-L60JL488A-69 Jeep Wrangler JL 4.88 ARB Air Locker
SF-L60JL538A-69 Jeep Wrangler JL 5.38 ARB Air Locker
SF-L60JT456A-69 Jeep Gladiator JT 4.56 ARB Air Locker
SF-L60JT488A-69 Jeep Gladiator JT 4.88 ARB Air Locker
SF-L60JT538A-69 Jeep Gladiator JT 5.38 ARB Air Locker
