Serious Strength for Serious Off-Roading

Now Dana Offers Crate Axles® for Installation in Virtually Any Application

Ultimate 60 LogoTake on the most brutal terrain with Ultimate Dana 60® Bracketless Crate Axles®: the biggest, strongest axles out there are now available from Dana for almost any off-road vehicle. Built with genuine Spicer® components, these mighty Crate Axles feature upgrades that give you a competitive advantage on the trail.

Bracketless Axles
All of the features; none of the brackets

Off-road enthusiasts will appreciate the massive SPL® 70 u-joints, heavy-duty upgraded brakes, nickel chromoly steel axle shafts, durable Spicer performance ring and pinion gears, and the aggressive nodular iron diff cover. Front Crate Axles feature the Dana-exclusive high clearance housing, while the rear axles utilize ultra-strong 3-1/2" tubes with 3/8" wall thickness.

Get the new Ultimate Dana 60® Bracketless Crate Axle straight from Dana, weld on the brackets that fit your rig, and get ready to overcome even the toughest obstacles.

Ultimate Dana 60® Bracketless Crate Axles incorporate the upgrades that off-roaders demand.

Get Unrivalled Durability for Your Custom Build

Trust Ultimate Dana 60® Bracketless axles to provide a higher torque load, and deliver peak protection from environmental contaminants. Get the performance and dependability of Ultimate Dana 60® for your custom build today!

Ultimate Dana 60® Bracketless axles provide maximum strength and durability for vehicles with larger tires, and feature:

  • Massive Spicer® SPL® 70 u-joints – exclusive to Dana
  • Spicer® 35 spline SAE-4340 nickel chromoly steel axle shafts
  • Warn® 35 spline hub locks
  • Dead spindle design
  • High-clearance carrier with ribbed housing design
  • Available with either an Eaton® ELocker® or ARB® Air Locker®
  • Heavy-duty 8 x 6.5" wheel bolt pattern
  • Genuine Made in the USA Spicer® 10" (256 mm) ring and pinion gear
  • Spicer® 1350 strap-style/half-round end yoke
  • Axle tubes: 3-1/2" tubes with 3/8" wall thickness
  • Upgraded heavy-duty brakes with plug-and-play ABS system
Differential Ratio Front Rear
E-Locker 3.73 10064659 10055395
E-Locker 4.10 10064660 10055396
E-Locker 4.88 10064658 10055398
E-Locker 5.38 10064657 10055400
ARB (Air Locker) 4.88 10146346 10144196
ARB (Air Locker) 5.38 10146347 10144198

To discover all the features and benefits of Ultimate Dana 60® axles, download the brochure on the right. Then, contact your Spicer parts dealer to gain a true competitive advantage with high-performance Ultimate Dana 60® Bracketless Crate Axles®.
